Wet Wire Drawing Machine
200000 INR/Unit
Product Details:
- Product Type Wet Wire Drawing Machine
- Wire Material Mild Steel, Stainless Steel, Copper, Aluminum
- Inlet Diameter 1.2 mm 6.5 mm
- Outlet Diameter 0.1 mm 1.2 mm
- Voltage 380V / 415V / 440V, 3 Phase, 50/60 Hz
- Power 7.5 kW 45 kW
- Dimension (L*W*H) 3800 mm x 900 mm x 1800 mm (approx.)
- Click to View more
X
Wet Wire Drawing Machine Price And Quantity
- 1 , , Unit
- 200000 INR/Unit
- Automatic/Semi-Automatic
- 250 mm 560 mm
- 5 m/s 25 m/s
- 300 kg/hr 800 kg/hr
- AC Drive/Variable Frequency Drive
- Integral Wet Type
- Below 75 dB(A)
- 7 to 24 (as per model)
- Fine and Super Fine Wire Production
- Heavy Gauge Steel Structure
- Water Circulation with Oil Emulsion
Wet Wire Drawing Machine Product Specifications
- 3800 mm x 900 mm x 1800 mm (approx.)
- Blue / Custom options
- Continuous wet wire drawing for thin wire manufacturing
- 380V / 415V / 440V, 3 Phase, 50/60 Hz
- 0.1 mm 1.2 mm
- 1.2 mm 6.5 mm
- 2500 kg 3500 kg (approx.)
- Mild Steel, Stainless Steel, Copper, Aluminum
- 7.5 kW 45 kW
- Wet Wire Drawing Machine
- Automatic/Semi-Automatic
- 250 mm 560 mm
- 5 m/s 25 m/s
- 300 kg/hr 800 kg/hr
- AC Drive/Variable Frequency Drive
- Integral Wet Type
- Below 75 dB(A)
- 7 to 24 (as per model)
- Fine and Super Fine Wire Production
- Heavy Gauge Steel Structure
- Water Circulation with Oil Emulsion
Wet Wire Drawing Machine Trade Information
- 15 , , Unit Per Month
- 15 Days
Product Description
For several years, our organization has been involved in offering a wide array of Wet Wire Drawing Machine. The provided machine is well suited for drawing and coiling copper and wires. This machine is precisely engineered using world class components with the use of modish techniques by our deft technocrats. Furthermore, this Wet Wire Drawing Machine is available to the patrons in different specifications at feasible prices.
Features:
- Fully automatic operation
- Longer service life
- Optimal performance
- Robust construction
Product details
| Brand | AE |
| Max Inlet Wire Diameter | 3-6 mm |
| Frequency | 50-60 Hz |
| Min Finish Wire Diameter | 0-1 mm |
| Layout | Horizontal |
| Automation Grade | Automatic |
Advanced Wire Drawing Capabilities
This machine is tailored for the production of thin wires, catering to both fine and super fine gauge requirements. The customizable die configurations (from 7 up to 24) allow for flexibility based on the desired output, ensuring consistent wire quality regardless of material type. Coupled with high-speed operation and precision controls, it supports diverse manufacturing demands.
Efficient Cooling and Lubrication System
Equipped with an integral wet type lubrication and water circulation with oil emulsion cooling, the machine minimizes wire breakage and ensures a smooth, glossy finish on drawn wires. This advanced system extends the lifespan of dies and supports continuous, high-speed production while maintaining noise levels below 75 dB(A) for a quieter workspace.
Robust and User-Friendly Construction
The heavy gauge steel structure provides durability and long service life, while the automatic or semi-automatic operation modes streamline production and reduce manual intervention. The machines intuitive interface and safety features make it easy to operate, enhancing productivity across wire manufacturing facilities.
FAQs of Wet Wire Drawing Machine:
Q: How does the integral wet lubrication system benefit the wire drawing process?
A: The integral wet lubrication system continuously coats the wire and dies with lubricant, reducing friction and heat generation during drawing. This not only improves wire surface finish but also extends die life, allowing for higher speeds, reduced wear, and consistent wire quality throughout production.Q: What materials can be processed with this wet wire drawing machine?
A: The machine is versatile and designed to handle multiple wire materials, including mild steel, stainless steel, copper, and aluminum. This flexibility makes it ideal for producing a range of fine and super fine wires required across various industries.Q: When should I choose the automatic operation mode over semi-automatic?
A: Automatic mode is recommended when continuous production with minimal human intervention is desired, ensuring maximum consistency and efficiency. Semi-automatic mode may be suitable for smaller batches or when operator oversight is needed for prototyping or custom projects.Q: Where is the wet wire drawing machine ideally installed?
A: This machine is best suited for wire manufacturing plants, industrial workshops, and export-oriented facilities that require reliable, high-throughput wire production. Its compact footprint and low noise operation make it practical for both large and moderately sized production environments.Q: What is the typical process of using this wet wire drawing machine?
A: Begin by loading the inlet wire (1.2 mm 6.5 mm diameter) and selecting the appropriate die configuration. The machine automatically draws, lubricates, and cools the wire as it passes through the dies, reducing diameter to the desired size (down to 0.1 mm). Finished wire is collected continuously, with minimal manual adjustment required.Q: How does the machine ensure energy efficiency during operation?
A: Equipped with AC drive or variable frequency drive technology, the machine optimizes motor energy usage by adjusting speeds based on load and process requirements. This not only reduces power consumption (7.5 kW 45 kW) but also supports precise speed control for enhanced process stability and efficiency.Tell us about your requirement
